2024 Ducati Panigale V4 S at Steele Recreation

Standard

• Compression Ratio : 14.0:1
• Engine : Desmosedici Stradale 90° V4, counter-rotating crankshaft, 4 Desmodromic timing, 4 valves per cylinder, liquid-cooled
• Displacement : 1,103 cc
• Bore x Stroke : 82 x 53.5 mm
• Power : 154.5 kW (210 hp) @ 12,500 rpm
• Torque : 122.8 Nm (90.6 lb-ft) @ 11,000 rpm
• Fuel Injection : Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system
• Exhaust : 4-2-1-2 system, with 2 catalytic converters and 4 lambda probes

Standard

• Gearbox : 6 speed with Ducati Quick Shift (DQS) up/down EVO 2
• Primary drive : Straight cut gears; Ratio 1.80:1
• Ratio : 1=36/15 2=34/17 3=33/19 4=32/21 5=30/22 6=27/22
• Final drive : Chain 525; Front sprocket 16; Rear sprocket 41
• Clutch : Hydraulically controlled slipper dry clutch. Self bleeding master cylinder

Standard

• Frame : Aluminum alloy "Front Frame" with optimized stiffnesses
• Front suspension : Öhlins NPX25/30 pressurized 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode
• Front Wheel : 3-spokes forged aluminum alloy 3.50 in x 17 in
• Front Tire : Pirelli Diablo Supercorsa SP 120/70 ZR17
• Rear Suspension : Fully adjustable Öhlins TTX36 monoshock. Aluminum single-sided swingarm
• Rear Wheel : 3-spokes forged aluminum alloy 6.00 in x 17 in
• Rear Tire : Pirelli Diablo Supercorsa SP 200/60 ZR17
• Wheel Travel (Front/Rear) : 125 mm (4.9 in) - 130 mm (5.1 in)
• Front Brake : 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema (M4.30) 4-piston callipers with Bosch Cornering ABS EVO. Self bleeding master cylinder
• Rear Brake : 245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO
• Instrumentation : Last generation digital unit with 5 in TFT colour display

Standard

• Safety Equipment : Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 3, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO 2, Auto tyre calibration
• Standard Equipment : Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Ducati Electronic Suspension (DES) EVO with Öhlins suspension and steering damper, Quick adjustment buttons, Lithium-ion battery, Auto-off indicators, Marchesini aluminium forged wheels, Racing style handle grips, Chain guard, Provided Equipment, Passenger seat and footpegs kit
• Ready for : Ducati Data Analyser+ (DDA+) with GPS module, Ducati Multimedia System (DMS), Anti-theft, Heated grips
• Additional equipment: Passenger seat and footrest kit

Standard

• Dry Weight : 174 kg (384 lb)
• Curb Weight : 195.5 kg (431 lb)
• Seat Height : 850 mm (33.5 in)
• Wheelbase : 1.469 mm (57,8 in)
• Rake : 24,5°
• Trail : 100 mm (3,94 in)
• Fuel tank capacity : 17 l - 4.5 gallon (US)
• Number of Seats : Dual seats

Standard

• Warranty : 24 months unlimited mileage
• Maintenance Service Intervals : 12,000 km (7,500 m)/12 months
• Valve clearance adjustment : 24,000 km (15,000 m)
